The CRUSADER is the latest adaptation of the very successful SAMURAI HULL featuring:

  • Increased rising dead rise (sharper entry) – improved ride,
  • Increased waterline width (greater planning surface area) – faster planning,
  • Increased reverse chine – an even drier ride with maximum stability,
  • Swept bow – increased depth of sides.

The Crusader runabout features latest swept bow configuration in a runabout giving a greater feeling of safety up the front of the boat and the soft ride of the Samurai Hull is a pleasure to feel.
A walk through dash and screen allows for easy anchoring and fully upholstered swivel seats in the front and fully upholstered removable rear lounge with padded back rest gives the whole family a comfortable ride. The Crusader is a perfect mix of a roomy family boat with a good fishing platform.

This exciting new model replaced the Capri as the premium runabout in the range in 2016, with the BAY SEEKER remaining as the entry level runabout from Sea Jay Boats.

Ultimate Edge 2 logo
Bottoms high tensile 5083 plate (mm) 4.0 4.0
Plate sides (mm) 3.0 3.0
Beam (m) 2.3 2.4
Depth (m) 1.25 1.29
Depth including screen (m) 1.58 tbc
Floor ribs 12 13
Length overall 5.22 5.52
Number of persons 5 5
Weight approx (kg) 520 tbc
Maximum hp 90 115
Maximum motor weight (kg) 175 195
Note – Specifications may vary slightly. Features / options are subject to change without notification.


FEATURES  4.90  5.20
Anchor well
Bait tank plumbed – alloy
Battery & oil rack in stern
Boarding ladder – heavy duty
Windscreen with grab rails
Walk through windscreen
Dashboard & glovebox
bollard x 3 3 3
Bow sprit & roller
Bungs 38mm 1 1
Dive door opt
Drink holder 2 2
Storage under walk through
Flotation – under floor
Floor – carpet / plywood
Gunwhale rubber insert
Painted – chine up & inside
Pin stripes
Platinum sides (3mm plate)
5083 plate 4mm bottoms with capped keel & welded strakes
Rod holders (plastic) 4 4
Side pockets
Spray chines
Steering – hydraulic opt
Steering – mechanical
Samurai hull
Towing eye (double)
Transducer bracket – Dual
Wide side decks – fully welded on top
Transom tied down eyes
Ultimate Edge 2 – LS 20″
Ultimate Edge 2 – XL 25″
Under floor / gunwale filler / gauge 100ltr 150ltr
Heavy duty 32mm low bow rails
Windscreen grab rail
Heavy duty 32mm rear transom rails
Accessory pre rig loom with battery box & isolation switch
6 gang switch panel / bilge pump / navigation, stern & anchor light
Fully upholstered bucket swivel seats & pedestal
Removable rear lounge with fixed padded back rest

Note – Specifications may vary slightly. Features / options are subject to change without notification.

OPTIONS  4.90  5.20
Paint upgrade to color (white or pipeline grey are standard) opt opt
Vinyl wrap opt opt
Bilge pump upgrade to auto opt opt
Hydralic steering upgrade opt
Anchor well reinforced to suit winch included Sarca bow sprit opt opt
Upgrade plastic rod holders to alloy opt opt
Sea Jay Trailer. Earn extra 12 months Warranty at no extra charge opt opt
Spare wheel kit opt opt
Hatch cover over transom cutouts opt opt
Bait board removable opt opt
Boat board removable with ski pole opt opt
Bait board standard bolt on opt opt
Dive / transom door opt std
Note – Specifications may vary slightly. Features / options are subject to change without notification.


Gain an Extra 12 months Warranty for FREE when you buy a new Sea Jay Boat / Sea Jay Trailer combo.

4.90 5.20
Sea Jay (Steel) – OS-RS510-MO 1500kg
Sea Jay (Steel) – OS-RS510-MO 1650kg


4.90 5.20
Sea Jay (Alloy) – OS-TA500-MOB 1650kg
Sea Jay (Alloy) – TA500-MOB 1650kg  –



Crusader Video
