Plate Xtreme Freedom

ADDITIONAL INFO

The “Ultimate Fishing Platform” is not a term that can be thrown around lightly, however our Freedom plate alloy models with 360deg of fishable area would come very close. Developed as a Centre Cab, the Freedom allows full movement around the deck with ease when that elusive Mackerel or King fish decides to nosedive under the Boat. Like all Plate Xtreme models, the Freedom features, solid internal bulkheads, stringers and keel, reverse chine hull, a massive fuel capacity and of course a style and flair that will make you the envy of other Boaties out on the water.

FREEDOM BOATS PACKAGES
MAKE AN ENQUIRY
The “Ultimate Fishing Platform” is not a term that can be thrown around lightly, however our Freedom plate alloy models with 360° of fishable area would come very close.

VIDEO – 6.0 FREEDOM

VIDEO – 6.4 FREEDOM

VIDEO – 6.8 FREEDOM

https://youtu.be/kxyWnvLHMEM

Specifications 670 770 805
3D designed & CNC cut within factory • • •
bottoms (mm) 5.0 5.0 5.0
sides (mm) 4.0 4.0 4.0
transom (mm) 5.0 5.0 5.0
stringers – longitudinal (mm) 5.0 5.0 5.0
bulkheads – solid (mm) 4.0 4.0 4.0
keel – solid (mm) 5.0 5.0 5.0
beam (m) 2.49 2.49 2.49
overall length (m) 6.93 7.39 8.17
dead rise (deg) (at transom) 19.5 19.5 20
depth (m) 1.6 1.67 1.73
depth (m) – cabin step down floor to cabin roof 1.57 1.57 1.57
depth (m) – internal floor to top of side deck (freeboard) .71 0.71 0.76
depth (m) – keel to top of rocket launcher 2.81 2.81 2.91
no. of persons (at 80kg per person) 7 7 7
weight – boat (dry) / motor / Trailer (kg) (weight is approximate & depends on engine/options) 2170 2465 2750
rec hp 150 200 225 – 250
max hp 200 250 300
max motor weight (kg) 350 390 460
STANDARD HULL INCLUSIONS 670 770 805
anchorwell • • •
anchorwell mounting plate to suit stress free anchor winch • • •
bait tank cavity (alloy) • • •
battery (suits dual) & oil rack – in transom • • •
bollards – 1 x front, 2 x rear • • •
bow sprit – dual rollers • • •
bungs – alloy 38mm x 2 • • •
cabin drop down foot well (drained) • • •
cabin storage – under bunks • • •
cabin hatch (alloy) with support stay – (740mm x 57mm opening)) • • •
floor – 3mm alloy foot well (drained) • • •
flotation – foam / air chambers • • •
foot rest – driver & passenger side • • •
gunwhale shelf x 2 • • •
hard top – alloy • • •
instrumentation dash • • •
overhead radio console • • •
reverse chine hull • • •
side pockets x 2 • • •
spray deflector strake • • •
steering assembly cover • • •
towing eye (double) – heavy duty • • •
transducer / trim tab mounting brackets x 2 • • •
transom boarding platform – non skid • • •
wide side decks (230mm total width) • • •
STANDARD FITOUT INCLUSIONS
bait board – alloy • • •
bait tank plumbing (with power stream aerator) • • •
boarding ladder – heavy duty • • •
cabin bunk cushions • • •
cabin windows x 2 • • •
carpeted floor – marine grade • • •
dive door • • •
flow-rite qwik-lok hose connections • • •
gunwhale rubber insert • • •
hood lining – cabin (roof & sides) • • •
hood lining – hardtop • • •
inspection port x 2 (in cockpit floor) • • •
moulded transom hatch x 2 (in transom shelf) • • •
moulded transom hatch x 1 (in transom boarding platform) • • •
paint – white / fleck (2 pac commercial marine grade) • • •
pin striping • • •
rocket launcher (alloy) – includes 8 rod holders • • •
rod holders (alloy) x 6 – in wide side decks • • •
scuppers (for self draining deck) x 2 • • •
seat frame – 3mm alloy x 2 (with provision to fit an icebox) • • •
tackle tray • • •
windscreen – contoured sports • • •
ELECTRICAL
accessory pre rig loom – to suit dual battery • • •
battery box x 2 • • •
battery master / isolation switch BEP x 2 • • •
bilge pump • • •
light (LED) – cabin x 1 • • •
light (LED) – underside of hardtop x 1 • • •
light (LED) – anchor folding (on hard top) • • •
light (LED) – navigation • • •
light (LED) – stern • • •
power socket 12v • • •
switch panel BEP (6 gang) x 2 • • •
FUEL TANK
under floor / deck fill 300ltr 360ltr 500ltr
fuel hose cover • • •
fuel sender • • •
separate fuel cell (tank within it’s own cavity) • • •
RAILS
bow – low profile (32mm) • • •
grab rail – around hard top (25mm) • • •
grab rail – passenger (25mm) • • •
transom (32mm) • • •
SEATS
full upholstered seats opt opt opt
offshore bucket seats x 2 • • •
seat slide – driver & passenger side • • •
STEERING
hydraulic steering – Sea Star – • •
sports steering wheel • • •
TRANSOM
filled in – 25″ • • •
twin engine opt opt opt
FACTORY OPTIONS
anchor winch – electric opt opt opt
anchor winch rope kit opt opt opt
bunk centre filled in opt opt opt
cabin door cover – vinyl with fly screen opt opt opt
checkerplate floor opt opt opt
coloured sides – paint (2 pac commercial marine grade) opt opt opt
deck wash 19ltr / min – fresh water (includes 75ltr water tank) opt opt opt
deck wash 19ltr / min – fresh water (includes 125ltr water tank) – – opt
deck wash 19ltr / min – (salt water ) opt opt opt
front clears opt opt opt
rear bimini – off rear of hard top opt opt opt
self flooding kill tank (may lose fuel capacity) opt opt opt
seat box DLX – with sink / storage / moulded hatch opt opt opt
seat box DLX – with rear seat / storage / moulded hatch opt opt opt
spot light – LED opt opt opt
tackle tray opt opt opt
toilet (chemical) – under cabin bunk opt opt opt
trim tabs – electric opt opt opt
ice box – 110ltr fiberglass with split lid (fits in seat frame) opt opt opt
ice box upholstery – to suit 110ltr fiberglass with split lid opt opt opt
