ADDITIONAL INFO
Want more Deck space? How about an area to hide you esky? Our Striker model has all this and more. The console has been positioned towards the stern of the Boat to maximise deck space allowing for a huge fishing platform or simply an area to roll out the swag for an overnight trip. In the step up Floor, not one but two under floor dry storage cavities can be found with one cavity large enough to stow away an Esky to help keep the top deck clutter free. A massive fuel tank has been squeezed under the floor allowing you to feel confident knowing that you can reach your favourite fishing destination with plenty of fuel to spare.
The “Ultimate Fishing Platform” is not a term that can be thrown around lightly, however our Freedom plate alloy models with 360° of fishable area would come very close.
Specifications | 550 | 610 |
3D designed & CNC cut within factory | • | • |
bottoms (mm) | 5.0 | 5.0 |
sides (mm) | 4.0 | 4.0 |
transom (mm) | 5.0 | 5.0 |
stringers – longitudinal (mm) | 4.0 | 4.0 |
bulkheads – solid (mm) | 3.0 | 3.0 |
keel – solid (mm) | 5.0 | 5.0 |
beam (m) | tba | 2.45 |
overall length (m) | tba | 6.34 |
dead rise (deg) (at transom) | tba | 18 |
depth (m) | tba | 1.55 |
depth (m) – keel to top of console screen | tba | 1.94 |
depth (m) – internal floor to top of side deck (freeboard) | tba | 0.7 |
no. of persons (at 80kg per person) | 5 | 6 |
weight – boat (dry) / motor / Trailer (kg) (all factory options & max motor weight) | tba | tba |
rec hp | 115 | 130 |
max hp | 130 | 150 |
max motor weight (kg) | 195 | 230 |
STANDARD HULL INCLUSIONS | 550 | 610 |
anchorwell | • | • |
anchorwell mounting plate to suit stress free anchor winch | • | • |
bait tank cavity 40ltrs (alloy) | • | • |
battery (suits dual) & oil rack – in transom | • | • |
bollards – 1 x front, 2 x rear | • | • |
bow sprit – dual rollers | • | • |
bungs – alloy 38mm x 2 | • | • |
console – side towards rear | • | – |
console – centre towards rear – with shelf | – | • |
dry storage in front floor | • | • |
esky storage cavity | • | • |
floor – 3mm alloy fully welded self draining | • | • |
flotation – foam / air chambers | • | • |
foredeck – rounded | • | • |
reverse chine hull | • | • |
side pockets (extra long) x2 | • | • |
spray deflector strake | • | • |
step up floor | • | • |
towing eye (double) – heavy duty | • | • |
transducer / trim tab mounting brackets x 2 | • | • |
transom boarding platform – non skid | • | • |
wide side decks (230mm total width) | • | • |
STANDARD FITOUT INCLUSIONS | ||
bait board – Alloy (includes 2 rod holder) | • | • |
bait tank plumbing (with Power Stream Aerator) | • | • |
boarding ladder – heavy duty | • | • |
carpeted floor – marine grade | • | • |
console windscreen | • | • |
dive door | • | • |
flow-rite qwik-lok hose connections | • | • |
gunwhale rubber insert | • | • |
inspection port x 2 (in cockpit floor) | • | • |
inspection port x 1 (in transom boarding platform) | • | • |
paint – white / fleck (2 pac commercial marine grade) | • | • |
pin striping | • | • |
rod holders (alloy) x 6 – in wide side decks | • | • |
scuppers (for self draining deck) x 2 | • | • |
ELECTRICAL | ||
accessory pre rig loom – to suit dual battery | • | • |
battery box x 2 | • | • |
battery master / isolation switch BEP x 2 | • | • |
bilge pump | • | • |
light (LED) – anchor | • | • |
light (LED) – navigation | • | • |
light (LED) – stern | • | • |
power socket 12v | • | • |
switch panel BEP (6 gang) x 1 | • | • |
FUEL TANK | ||
under floor / deck fill | 140ltr | 200ltr |
fuel hose cover | • | • |
fuel sender | • | • |
separate fuel cell (tank within it’s own cavity) | • | • |
RAILS | ||
bow – low profile (32mm) | • | • |
console | • | • |
transom (32mm) | • | • |
SEATS | ||
2 x pedestals with part upholstered seats | • | • |
Sockets | 5 | 6 |
STEERING | ||
hydraulic steering – Baystar | • | • |
sports steering wheel | • | • |
TRANSOM | ||
25″ | • | • |
FACTORY OPTIONS | ||
anchor winch – electric | opt | opt |
anchor winch rope kit | opt | opt |
checkerplate floor | opt | opt |
coloured sides – paint (2 pac commercial marine grade) | opt | opt |
deck wash 19ltr / min (saltwater) | opt | opt |
120ltr plastic esky (suits esky cavity) | opt | opt |
trim tabs – electric | opt | opt |
