PLATE XTREME STRIKER

Want more Deck space? How about an area to hide you esky? Our Striker model has all this and more. The console has been positioned towards the stern of the Boat to maximise deck space allowing for a huge fishing platform or simply an area to roll out the swag for an overnight trip. In the step up Floor, not one but two under floor dry storage cavities can be found with one cavity large enough to stow away an Esky to help keep the top deck clutter free. A massive fuel tank has been squeezed under the floor allowing you to feel confident knowing that you can reach your favourite fishing destination with plenty of fuel to spare.

The “Ultimate Fishing Platform” is not a term that can be thrown around lightly, however our Freedom plate alloy models with 360° of fishable area would come very close.

Download Striker Flyer
VIDEO – 5.1 STRIKER
VIDEO – 5.6 STRIKER
  • SPECS
  • FEATURES
  • GALLERY
  •   5.1 5.6 6.0
    3D designed & CNC cut within factory
    bottoms (mm) 4.0 4.0 5.0
    sides (mm) 4.0 4.0 4.0
    transom (mm) 4.0 4.0 4.0
    stringers – longitudinal (mm) 4.0 4.0 4.0
    bulkheads – solid (mm) 3.0 3.0 3.0
    keel – solid (mm) 4.0 4.0 4.0
    beam (m) 2.25 2.3 2.3
    hull length (m/ft) 5.15/16.9 5.68/18.5 5.98/19.5
    overall length (m/ft) 5.45/17.9 5.96/19.5 6.26/20.5
    dead rise (deg) (at transom) 17 17.5 19
    distance between bulkheads (mm) 525 (avg) 500 (avg) 600 (avg)
    depth (m) 1.29 1.31 tba
    depth (m) – keel to top of console screen 1.64 1.94 tba
    depth (mm) – internal floor to top of side deck (freeboard) 580 640 tba
    no. of persons (at 80kg per person) 5 6 6
    weight – hull only (kg) (includes all factory options) 645 710 tba
    weight – boat (dry) / motor / Trailer (kg) (all factory options & max motor weight) 1270 1335 tba
    rec hp 80 115 115
    max hp 115 150 150
    max motor weight (kg) 195 230 240
  • STANDARD HULL INCLUSIONS 5.1 5.6 6.0
    anchorwell
    anchorwell mounting plate to suit stress free anchor winch
    bait tank cavity 40ltrs (alloy)
    battery (suits dual) & oil rack – in transom
    bollards – 1 x front, 2 x rear
    bow sprit – dual rollers
    bungs – alloy 38mm x 2
    console – side towards rear
    console – centre towards rear – with shelf
    dry storage in front floor
    esky storage cavity
    floor – 3mm alloy fully welded self draining
    flotation – foam / air chambers
    foredeck – rounded
    reverse chine hull
    side pockets (extra long) x2
    spray deflector strake
    step up floor
    towing eye (double) – heavy duty
    transducer / trim tab mounting brackets x 2
    transom boarding platform – non skid
    wide side decks (230mm total width)
    STANDARD FITOUT INCLUSIONS
    bait board – Alloy (includes 2 rod holder)
    bait tank plumbing (with Power Stream Aerator)
    boarding ladder – heavy duty
    carpeted floor – marine grade
    console windscreen
    dive door
    flow-rite qwik-lok hose connections
    gunwhale rubber insert
    inspection port x 2 (in cockpit floor)
    inspection port x 1 (in transom boarding platform)
    paint – white / fleck (2 pac commercial marine grade)
    pin striping
    rod holders (alloy) x 6 – in wide side decks
    scuppers (for self draining deck) x 2
    ELECTRICAL
    accessory pre rig loom – to suit dual battery
    battery box x 2
    battery master / isolation switch BEP x 2
    bilge pump
    light (LED) – anchor
    light (LED) – navigation
    light (LED) – stern
    power socket 12v
    switch panel BEP (6 gang) x 1
    FUEL TANK
    under floor / deck fill 140ltr 200ltr 240ltr
    fuel hose cover
    fuel sender
    separate fuel cell (tank within it’s own cavity)
    RAILS
    bow – low profile (32mm)
    console
    transom (32mm)
    SEATS
    2 x pedestals with part upholstered seats
    Sockets 5 6 6
    STEERING
    hydraulic steering – Baystar
    sports steering wheel
    TRANSOM
    25″
    FACTORY OPTIONS
    anchor winch – electric opt opt opt
    anchor winch rope kit opt opt opt
    checkerplate floor opt opt opt
    coloured sides – paint (2 pac commercial marine grade) opt opt opt
    deck wash 19ltr / min (saltwater) opt opt opt
    120ltr plastic esky (suits esky cavity) opt opt opt
    trim tabs – electric opt opt opt
